Listing# 577118

GML SPA CASE PACKER

Download High Res Photos

Make an Inquiry Add To Watch List

Seller's Acceptable Currency:

€10,700.00 EUR

Make An Offer

Location: Europe

Level of Removal: Uncrated/Loose

Why we recommend inspection

*All offers are submitted in Seller’s Acceptable Currency

Don't see what you're looking for? We'll find it for you

Equipment Description

DESCRIPTION:
Independent system, to be attached to a cartoning machine, intended for filling cardboard cases. The machine is composed of a structure in stainless steel AISI 304, equipped with wheels for movement. The unit is equipped with a cart head with suction cups for gripping of layer, moved by means of pneumatic units on two axes: horizontal and vertical. The vacuum necessary for the grip is achieved through the use of a Venturi-type system.

SECTORS OF USE:
Pharmaceutical, chemical, cosmetics, food, dietary, medical devices, manufacturing.

MAIN FEATURES:
Semi-automatic machine able to the grouping of products in boxes, their introduction into cartons previously taken from stock, formats and positioned at the entrance opened in such a way that enable the mobile hopper and the pusher to carry out the filling, which completed the two groups of transport side, which serve to maintain the correct squaring, convey the same to the exit. The machine stacks products and insert the bundles thus obtained into shipping cartons previously formed. This system allows the machine to minimize the drawbacks and waste. The case packer is composed of: base, conveyor belt for feeding the products, assembling station (stacking of products). The cartons arrive on the conveyor belt already packed. Two photocells give consent to the complete row pusher that will move the cartons in the case preformation area. Once the layer is complete it is deposited in the cardboard box.

Year of construction: 2009

TECHNICAL DATA
Length mm 1400
Width mm 600
Height mm 1500
Power absorbed kw 1,5
Frequency Hz 50
Voltage Volt 230
Phases 1
Compressed air bar 6

Specifications:

Standard

Metric

Manufacturer Name

GML

Year:

2009

CE Marked:

UNKNOWN

Model:

SPA

Air Requirements:

6 BAR

Type of Case:

UNKNOWN

Type of Packer:

PLACE

Case Sealing:

UNKNOWN

Voltage:

230 VOLTS

Frequency:

50 HERTZ

Phase:

Current:

1,5 KW

Recommended Packaging Form:

CUSTOM

Dimensions:

Standard

Metric

Overall:

55.12 x 23.62 x 59.06 in - 1763.68 lb

1400 x 600 x 1500 MM - 800 KGS

Disclaimer

This lot is being sold "as is, where is". We recommend that you contact an EquipNet sales representative to set up your own inspection. This item is located in

Europe.

This equipment is subject to a removal and loading charge.

The written description provided for this equipment is EXACTLY what you will receive if you opt to purchase this listing. Any items that are not in the description but appear in the visual representations of this listing will not be included in the sale. Photos and video are provided just as references and to give a general sense of condition.

Please be aware that weights and dimensions of equipment provided on EquipNet’s listings are estimates and can vary from actual weights and size. Sellers estimates are often not precise especially when equipment was installed versus prepped for shipment. As such, please do not fully rely on the accuracy of this information in EquipNet’s listings for shipping quotes and/or user size requirements.

Any license associated with this equipment is non-transferable.
