Listing# 421188

Novopac CD 090 F2 BM 1409 Automatic Shrink Bundler


Seller's Acceptable Currency:

€15,800.00 EUR

Make An Offer

Location:  Europe

Level of Removal:  Uncrated/Loose

Why we recommend inspection

*All offers are submitted in Seller’s Acceptable Currency

Don't see what you're looking for? We'll find it for you




Equipment Description
  • Novopac CD 090 F2 Automatic Shrink Bundler
  • Description:
  • Horizontal shrink bundler machine for the packaging of various products.
  • SECTORS OF USE: Pharmaceutical, chemical, cosmetics, food, dietary, medical devices, manufacturing.
  • MAIN FEATURES: The machine is supplied with a self-retaining manual stop. The presence of foreign body under the welding device or the infeed unit overloaded causes the automatic emergency stopping of the machine due to the action of safety micro switch.
  • The welder is supplied with teflon coating and spring support. The main motorization consists of a self-braking motor complete with expansible pulley for speed adjustment that has a fixed diameter pulley with fiction clutch, one chain for motion transmission from the reduction unit to the camshaft. By varying the diameter of the expansible pulley the machine speed changes. The input of the bundle in the welding area is made by means of the plate towed by a chain operated by a self-braking geared motor.
  • The product obtained from the filling station is oriented and gathered in front of the grip assembly. Once reached a minimum level the products can advance and the presence / the number of vials is verified. The bottles are picked up and the bundles are introduced in the wrapping and welding section. After welding, the burden coming next pushes the package on the conveyor belt of the tunnel.

  • Specifications:
    Standard
    Metric
    Manufacturer Name
    Novopac


    Year:
    2004
    2004

    Frequency:
    50/60 HERTZ
    50/60 HERTZ


    Dimensions:
    Standard
    Metric

    Overall:
    146 x 119 x 60 IN - 2866 LBS
    3708.40 x 3022.60 x 1524.00 mm - 1300.02 kg

    Disclaimer

    This lot is being sold "as is, where is". We recommend that you contact an EquipNet sales representative to set up your own inspection. This item is located in

    Europe.

    This equipment is subject to a removal and loading charge.


    The written description provided for this equipment is EXACTLY what you will receive if you opt to purchase this listing. Any items that are not in the description but appear in the visual representations of this listing will not be included in the sale. Photos and video are provided just as references and to give a general sense of condition.

    Please be aware that weights and dimensions of equipment provided on EquipNet’s listings are estimates and can vary from actual weights and size. Sellers estimates are often not precise especially when equipment was installed versus prepped for shipment. As such, please do not fully rely on the accuracy of this information in EquipNet’s listings for shipping quotes and/or user size requirements.

    Any license associated with this equipment is non-transferable.
