You are making an offer on a RA Jones Soap Cartoner located in Malaysia. This lot is being sold "as is, where is." We recommend that you contact an EquipNet sales representative to set up your own inspection.
This machine can do the following:
Able to run cartoned soap from 65gm
to 125gm
Soap bar dimensions:
65gm : 54mmx79mmx20mm [W,L,H]
125gm : 64mmx93mmx29mm
Soap carton dimensions :
65gm : 55mmx29mmx83mm [W,H,L]
125gm : 64mmx33mmx95mm
It has Dual infeed system , two infeed pick up units transfering bar soaps to a bucket chain conveyor. In line feeding and forming of cartons. Soap bars are pushed into the cartons using barrel loader system and sealed by hot melt glue.
Cartoner material of construction : Stainless steel ,Polycarbonate and Plastic. - Manufacturer R.A.Jones
- Year 1998
- Model CSC Legacy
- Serial Number S-5591
- Capacity Speed 300 BPM
- Product Sizing 65 gms - 125 gms
- Products Run Protex
- Spare/Change Parts Y
- Air Requirements 6 BAR
- Manual Available Yes
- Estimated Shipping Weight 500 KGS
- Maintenance Log/Records Available N
- MSDS Available N
- Length 6750 MM
- Width 1700 MM
- Height 2000 MM
- Voltage 415 VOLTS
- Frequency 50 HERTZ
- Phase 3 phase
- Current 8 AMPS
- Removal Difficulty EASY
- Product Handling HORIZONTAL
- Product Loading UNKNOWN
- Method of Code Dater UNKNOWN
- Line Motion UNKNOWN
- Accessories UNKNOWN
- Requires rigging or removal NO
- Requires a flatbed truck NO
- Level of shipment preparation necessary STILL INSTALLED
Contact Information
If you need further information, please contact our Sales Department at 888.371.6555, outside USA at +1.781.821.3482, or click here to send us a message, or by email to sales@EquipNet.com
Payment Methods:
Certified Check, Bank Check, Company Check w/Bank Guarantee, or Wire Transfer
Crating, Rigging, and Shipping Info:
Buyer is responsible for all crating and shipping charges. EquipNet can furnish a quote upon request. Please contact sales@equipnet.com.
Location:
Malaysia
Dimensions: 6750x1700x2000 MM
