DESCRIPTION:
Comminuting mill is used for the down sizing, grinding, pulverization and dispersion of wet and dry products in pharmaceutical, chemical, food, cosmetics, fertilizers industry etc. Controlled particle size reduction helps assure that the milled material will be consistent and repeatable with respect to color, uniformity, flowability, density. The product is fed from the top through in feed hopper and a rotary valve and material falls on the rotor blades beater assembly for milling or pulverization. Due to the knife edges mounted on rotor, the downsizing of particle takes place and gets pushed outward from the bottom opening.

SECTORS OF USE:
Pharmaceutical, chemical, cosmetics, food, dietary, medical devices, manufacturing.

MAIN FEATURES:
This comminutor operates by feeding material uniformly into the chamber in which a rotating blade assembly reduces the particles of the material by cutting or impacting them. The material discharges through a screen which regulates final particles size at the outlet of the milling chamber. The blade and screen act in conjunction to determine final product sizing. The mill is easy to be installed, dismantled and cleaned. All parts contacting materials are made of stainless steel, which is anti-acid and anti-corrosive, so that the machine is according with sanitary standard. The machine has the features of stable running, easy moving, low noise, high grinding efficiency, and low consumption of power. Knife edges can be removed for cleaning very easily. The unit is also equipped with a wall lifting system with a total height of 2500 mm.

TECHNICAL DATA
Dimensions mm 1000 x 860 x 2200
Weight kg 120
Product inlet/outlet diameter mm 450 / 150
Hopper capacity L 40
