Listing# 983130
Eurosicma - Flow Wrapper Model Euro 77 With TIV Feeder
Seller's Acceptable Currency:
$50,000.00 USD
Make An OfferLocation: Philippines
Level of Removal: Uncrated/Loose
*All offers are submitted in Seller’s Acceptable Currency
Don't see what you're looking for? We'll find it for you
Equipment Description
Eurosicma - Flow Wrapper Model Euro 77 With TIV Feeder
Horizontal automatic high speed cut and wrapping machine for small products such as Bubble-Gum, Toffee and
similar small products.
Technical Description of the Wrapper
Vibration resistant sturdy steel structure.
Transmission by means of epicycloidal gear box.
One reel holder with film compensation group for tention control with centering reel device and expansion blocking system.
Bi-directional print centering with correction intelligent correction of errors.
Product size
One pair of cold rollers for film feeding.
Two pairs of longitudinal rollers for heat seal.
'In Phase' Machine's stop.
Cross cutting and sealing rollers with multiple jaws and independent motorization, made to obtain a step optimal cut with respect to the dimensions of the products and higher wrapping speeds.
Automatic opening and closing of the sealing rollers.
Storage of the different size parameters.
Electrical panel and console combined in the machine, equipped with IP 54 protection, Forced ventilation .
10-inch graphic display equipped with messages and self-check.
Industrial standard PC.
'CAN BUS' field bus.
Brushless servomotors controlled on CAN BUS and with PC-resident format parameters.
Eurosicma - Envolvedora Flow Modelo Euro 77 Con Alimentador TIV
Máquina automática de corte y embalaje horizontal de alta velocidad para productos pequeños como chicle, caramelo y
Productos pequeños similares.
Descripción técnica de la envoltura
Estructura de acero resistente a las vibraciones.
Transmisión mediante caja de cambios epicicloidal.
Un portabobinas con grupo de compensación de película para control de tensión con dispositivo centrador de bobina y sistema de bloqueo de expansión.
Centrado de impresión bidireccional con corrección inteligente de errores.
Tamaño del producto
Un par de rodillos fríos para alimentación de película.
Dos pares de rodillos longitudinales para termosellado.
Parada de la máquina 'en fase'.
Rodillos transversales de corte y sellado con múltiples mordazas y motorización independiente, fabricados para obtener un paso de corte óptimo respecto a las dimensiones de los productos y mayores velocidades de envoltura.
Apertura y cierre automático de los rodillos de sellado.
Almacenamiento de los diferentes parámetros de tamaño.
Cuadro eléctrico y consola combinados en la máquina, equipados con protección IP 54, Ventilación forzada.
Pantalla gráfica de 10 pulgadas equipada con mensajes y autocomprobación.
PC estándar industrial.
Bus de campo 'CAN BUS'.
Servomotores Brushless controlados sobre CAN BUS y con parámetros de formato residente en PC.
similar small products.
Eurosicma - Envolvedora Flow Modelo Euro 77 Con Alimentador TIV
Productos pequeños similares.
Specifications:
Standard
Metric
Manufacturer Name
Eurosicma
Year:
2005
2005
Model:
Euro77/tiv
Euro77/tiv
Serial Number:
E77379
E77379
Voltage:
380
VOLTS
380
VOLTS
Frequency:
50
HERTZ
50
HERTZ
Current:
7.5
KW
7.5
KW
Recommended Packaging Form:
CRATE
CRATE
Dimensions:
Standard
Metric
Overall:
98.43 x 35.04 x 69.69 in - 2865.98 lb
2500 x 890 x 1770 MM - 1300 KGS
