DESCRIPTION: The PMA High Speed Granulator is a mixer suitable for high speed dispersion of dry powders, aqueous or solvent granulations and effervescent products. SECTORS OF USE: Pharmaceutical, chemical, cosmetics, food, dietary, medical devices, manufacturing. MAIN FEATURES: The overall concept of the New PMA-Compact stems from the common needs of consistent processing and ease of operation and cleaning. The mixing bowl is therefore shaped to wet granulate the widest range of products in a reproducible manner in respect of batch size, density and flow characteristics. Its shallow, wide diameter bowl guarantees a consistent product vortex and reduces any tendency towards product adhering to bowl walls. Product yields are further improved by the positioning of mixer blades close to the bowl base. A typical 3 minute dry mix operation is followed by introduction of a granulation fluid under pressure using a spraying unit. A free-flowing granulate is produced after 3-5 minutes, and the granules are then rapidly discharged. TECHNICAL DATA PRODUCTION CHARACTERISTICS Length mm 1610 Width mm 1600 Height mm 1300 Net weight Kg 600 PRODUCTION CHARACTERISTICS Volume 65 Lt Mixing Speed 40 – 400 rpm Granulator Speed (50 Hz) (rpm) 1500/3000 Granulator Speed (60 Hz) (rpm) 1800/3600 Nominal working capacity 25 Kg
