Listing# 1011174
Sapphire TK-3101 120L Stainless Steel Jacketed High Shear Mixing Tank Variable Speed and Portable
Seller's Acceptable Currency:
£11,000.00 GBP
Make An OfferLocation: Europe
Level of Removal: Uncrated/Loose
*All offers are submitted in Seller’s Acceptable Currency
Don't see what you're looking for? We'll find it for you
Equipment Description
Sapphire TK-3101 120L Stainless Steel High Shear Mixing Vessel Portable
Sapphire 120L Stainless, high shear mixing vessel, variable speed mixer, pressure vessel, jacketed with adjustable temp settings, bottom mounted high shear, central bottom discharge, mobile high shear mixing tank
Sapphire 120L Stainless, high shear mixing vessel, variable speed mixer, pressure vessel, jacketed with adjustable temp settings, bottom mounted high shear, central bottom discharge, mobile high shear mixing tank
Specifications:
Standard
Metric
Manufacturer Name
Sapphire Eng Ltd
Year:
2000
2000
CE Marked:
YES
YES
Capacity of Tank:
31.71
gal
120 L
Tank Material of Construction:
STAINLESS STEEL
STAINLESS STEEL
Grade of Stainless Steel:
316
316
Internal Pressure Rating:
3
BAR
3 BAR
Jacketed:
YES
YES
Jacket Pressure Rating:
5.5
BAR
5.5 BAR
Jacket Temperature Rating:
135
DEG C
135 DEG C
Type of Top Head:
DISHED
DISHED
Vertical or Horizontal:
VERTICAL
VERTICAL
Agitation:
YES
YES
How Many Types of Agitation :
SINGLE
SINGLE
Variable Frequency Drive:
YES
YES
Inside Diameter:
0.00
ft
0.0 M
Overall Height:
0.00
ft
0.0 M
Straight Side:
0.00
ft
0.0 M
Recommended Packaging Form:
CUSTOM PALLET
CUSTOM PALLET
Model:
TK-3101
TK-3101
Voltage:
240
VOLTS
240 VOLTS
Frequency:
50
HERTZ
50 HERTZ
Phase:
1
1
Dimensions:
Standard
Metric
Overall:
31.50 x 31.50 x 53.15 in - 496.04 lb
800 x 800 x 1350 MM - 225 KGS
Disclaimer
This lot is being sold "as is, where is". We recommend that you contact an EquipNet sales representative to set up your own inspection. This item is located in
Europe.
This equipment is subject to a removal and loading charge.
The written description provided for this equipment is EXACTLY what you will receive if you opt to purchase this listing. Any items that are not in the description but appear in the visual representations of this listing will not be included in the sale. Photos and video are provided just as references and to give a general sense of condition.
Please be aware that weights and dimensions of equipment provided on EquipNet’s listings are estimates and can vary from actual weights and size. Sellers estimates are often not precise especially when equipment was installed versus prepped for shipment. As such, please do not fully rely on the accuracy of this information in EquipNet’s listings for shipping quotes and/or user size requirements.
Any license associated with this equipment is non-transferable.
