The checkweigher for continuous weight control is made up of two structures on which are located the weight detection system on which the weighing conveyor weighs and the deviation system for incorrect packages. There is a feed conveyor which has the task of equally spacing the incoming packages and an output conveyor located downstream of the weighing conveyor on which the ejection device is located which has the task of diverting the out-of-tolerance and non-weighable packages from the line.
SECTORS OF USE:
Pharmaceutical, chemical, cosmetics, food, dietary, medical devices, manufacturing.
The checkweigher is part of a transporting line that controls objects of any type and shape. Going through the weighing surface takes a certain time. Although very short, this time is enough for the scales to take on a position that is proportioned to the weight of the product. After reading the weight, the packages pass on the outfeed conveyor on which the diversion system is located. The machine is not dependent on the downstream machine. The speed of the conveyor belts is adjustable.
Year of construction: 2001
Dimensions mm 1100 x 640 x 1620
Weight Kg 150
Voltage Volt 230
Frequency Hz 50
Power Kva 0,6
43.31 x 25.20 x 63.78 in - 330.69 lb
1100 x 640 x 1620 MM - 150 KGS
This lot is being sold "as is, where is". We recommend that you contact an EquipNet sales representative to set up your own inspection. This item is located in
This equipment is subject to a removal and loading charge.
The written description provided for this equipment is EXACTLY what you will receive if you opt to purchase this listing. Any items that are not in the description but appear in the visual representations of this listing will not be included in the sale. Photos and video are provided just as references and to give a general sense of condition.
Please be aware that weights and dimensions of equipment provided on EquipNet’s listings are estimates and can vary from actual weights and size. Sellers estimates are often not precise especially when equipment was installed versus prepped for shipment. As such, please do not fully rely on the accuracy of this information in EquipNet’s listings for shipping quotes and/or user size requirements.
Any license associated with this equipment is non-transferable.
