Listing# 1136011
Korsch X3 MFP Tablet Press
Pre-Owned Korsch Tablet Press for Sale
Seller's Acceptable Currency:
$250,000.00 USD
Request More Info Make An OfferLocation: NJ, USA
Level of Removal: Uncrated/Loose
*All offers are submitted in Seller’s Acceptable Currency
Don't see what you're looking for? We'll find it for you
Equipment Description
KORSCH X 3 MFP Tablet Press
Standard Machine Features (Included)
KORSCH X 3 MFP Tablet Press
Exchangeable Turret Capability
16-Station, TSM B Turret
Keyways in Upper Turret
GMP Compression Zone
Multi-Function Column (MFC)
Compression Roller Column, Pre and Main Compression
Motorized Adjustment – Tablet Thickness
Motorized Adjustment – Insertion Depth
Motorized Adjustment – Dosing Cam
2-Chamber Rotary, Variable Speed Force Feeder
Central Machine Control Diagnostic System
Composite Cam Track Design
Torque Drive on Main Motor
2-Channel Discharge Chute
4-Zone Central Lubrication System
Spring Load Cam Segment for Upper / Lower Punch Tight Detection
Set of Fill Cams (10 mm, 14 mm, 18 mm)
Water Cooling Unit for Torque Drive and Electrical Cabinet
Press Exterior in 304 Stainless Steel
Standard Control System Features (Included)
Siemens PLC Platform
19-Inch HMI Touch Screen on Stainless Steel Swing Arm
Windows 10 Operating System
480 VAC, 3-Phase, 60 Hz Main Power
Password Login
Product Recipe
Event Log (Electronic Audit Trail)
Fully Compliant with 21 CFR Part 11
Fully Prepared for Network Integration
9 2
© 2024 KORSCH AG · KAI-100924J – FINAL · 11.25.2024
KORSCH X 3 SFP TABLET PRESS
EQUIPMENT PROPOSAL
PharmaControl
®
(Included)
Display of Average Force – Precompression / Main Compression
Display of Single Forces by Punch Station – Precompression / Main Compression
Feedback to Dosing Cam for Precise Tablet Weight Control
Display of Standard Deviation of Main Compression Force
Entry of Press Force Limits – Precompression / Main Compression
Press Force Trending and Storage for Batch Report
Fully Functionality with Reduced Tools Configuration
Single Tablet Rejection (Included)
Pneumatic Tablet Blow-Off System
Rejects an Individual Tablet at All Press Speeds
Records and Displays Punch Station as Tablets are Rejected
Entry of Maximum Rejects from a Single Punch Station
Entry of Maximum Rejects from All Punch Stations
Reject Set-Up Parameters Stored in Product Recipe
Reject Log Report
Specifications:
Manufacturer Name
Year:
Serial Number:
Model:
No. of Stations:
Voltage:
Frequency:
Phase:
Current:
Recommended Packaging Form:
Dimensions:
Overall:
Asset Documents
Disclaimer:
DEA Regulated Sale
NOTE: Because this listing is a tabletting machine, capsule filler or encapsulation machine, the seller will need to notify the DEA of any transaction involving this machine. They will need to supply the DEA with the Model, Serial number, the buyer company, contact, address, telephone and fax number, and the buyer’s tax ID or DEA Registration number. The DEA requires at least 15 business days after payment has been received for this notification to occur before the press can be released for shipment. If you intend to make an offer on this machine you will be required to provide your company’s Tax ID or DEA Registration #.
This lot is being sold "as is, where is". We recommend that you contact an EquipNet sales representative to set up your own inspection. This item is located in
NJ
This equipment is subject to a removal and loading charge.
The written description provided for this equipment is EXACTLY what you will receive if you opt to purchase this listing. Any items that are not in the description but appear in the visual representations of this listing will not be included in the sale. Photos and video are provided just as references and to give a general sense of condition.
Please be aware that weights and dimensions of equipment provided on EquipNet’s listings are estimates and can vary from actual weights and size. Sellers estimates are often not precise especially when equipment was installed versus prepped for shipment. As such, please do not fully rely on the accuracy of this information in EquipNet’s listings for shipping quotes and/or user size requirements.
Any license associated with this equipment is non-transferable.
